| ELEPHANT TRUNK WIRE DRAWING MACHINE | |
| Machine | 12D |
| Inler diameter | ￠2.0-￠2.2 |
| Outer diameter | ￠0.9-￠1.2 |
| Max.speed | 700 |
| Max.number of drawing dies | 12 |
| Slip ratio of m/c | 17.50% |
| Fix speed capstan slip ratio | 14.5% |
| Capstan | grc15 |
| Max.capstan dia | ￠350 |
| Fix speed capstan dia | ￠260 |
| Frame | Steel plate welding |
| Main machine power | 30KW three-phase AC motor |
| Spooler power | 4KW three-phase AC motor |
| Corrention system | Full linear automatic control of take-up tension |
| Dynamic contronl | Frequency conversion Control |
| Transmission method | Timing belt |
| Pay-off method | the ends of formula |
| Trasmising method | Stepper motor |
| Tension control | Swing arm type balance rod |
| Lubrication system of drawing | Immersion |
| Suitable spool | ф300,ф350 |
| Service voltage | 380V |
| Brake | Electromagnetic brake |
| Machine dimension | 3450x900x1350 |
| Machine weight | 2200 |
